TE Connectivity IDCM-5 DC Input Module,5VDC
(43 ulasan)
| SKU: SKU001525
Rp975.000
Lihat deskripsi & spesifikasi lengkap
- 100% Produk Original / OEM
- Bergaransi resmi toko
- Retur 7 hari untuk barang cacat / salah kirim
- Pengemasan aman & rapi
Pre Order — barang akan disiapkan setelah pesanan dikonfirmasi
Deskripsi Produk
| Manufacturer Part Number | IDCM-5 |
|---|---|
| Manufacturer | TE Connectivity |
| Mounting Type | PCB Mount |
| Module Type | DC Input |
| Minimum Operating Temperature | -30 °C |
| Maximum Operating Temperature | 80 °C |
| Number of IO Ports | 1 |
| Number of Channels | 1 |
| Series | IDCM Series |
| Input Current | 34 mA A |
| Input Type | Digital |
| Isolation Voltage | 4000 VAC |
| For Use With | 2IO Series Mounting Board |
| Special Features | Optical Isolation |
| Supply Voltage | 6 VDC |
| Voltage Rating | 30 V |
| Turn On Time | 1 ms |
| Turn Off Time | 1 ms (Nom.) |
| Temperature Operating Range | -30 to +80 C |
| Range Output | 0 to 30 VDC |
| Output Type | Digital |
| Primary Type | Module |
| Alternate Mfr Part Number | 2-1393028-0 |
| Type | Input |
| Standards | Ul Recognized, CSA Certified |
| Current Rating | 0.05 A |
| Connection to Host | Circuit Board |
Slim line input/output modules provide interfacing between microprocessor- or computer-based control systems and external input devices and loads such as switches, sensors, valves and motor starters. Offered in four photo-isolated versions — AC input, AC output, DC input, DC output. Units are color-coded and have high isolation and noise immunity. Packaged in a 0.4" enclosure for replacement without disturbing wiring. On modules of the same voltage, output is compatible with input of the input module. Ideal for series operation. 1 Form A (SPST-NO).
