Storm Interface PLX120203 Keypad, 99.50 mm L x 11.1 mm Thickness, Panel Mount, 118.5 mm, 24 VDC (Max.)
- 100% Produk Original / OEM
- Bergaransi resmi toko
- Retur 7 hari untuk barang cacat / salah kirim
- Pengemasan aman & rapi
Deskripsi Produk
| Actuator Color | White |
|---|---|
| Actuator Material | Chromed Die Cast Zinc |
| Brand | Storm Interface |
| Case Color | Black |
| Case Material | Super Impact Polymer |
| Contact Material | Gold on Nickel Plated FR4 |
| Contact Resistance | 100 mOhms |
| Current Rating | 50 mA |
| Dimensions | 4.67 in H |
| Housing Color | Black |
| Insulation Resistance | 50 MOhms |
| Keypad Color | White |
| Legend | Engraved |
| Manufacturer Part Number | PLX120203 |
| Maximum Operating Temperature | 100 °C |
| Minimum Operating Temperature | -40 °C |
| Mounting Type | Panel Mount |
| Number of Keys | 12 |
| Operating Temperature | -40 to 100 °F |
| Output Type | Matrix |
| Primary Type | Keypad |
| Series | PLX Series |
| Size | 99.50 mm L x 11.1 mm Thickness in |
| Temperature Operating Range | -40 to +100 C |
| Type | Metal Key top |
| Voltage Rating | 24 V |
Storm 1000 PLX Series keypads are ideal for use in areas where toughness and resistance to water and dust is required. PLX Series keypads are cased in super high impact polymer to resist abuse and attacks. Chromed metal key tops are retained to provide key top graphics with unsurpassable toughness and wear resistance.
Features:
• Manufactured to survive hard use and abuse under extreme environmental conditions
• Rugged, reliable and responsive data entry
• Weather, water and dust resistant (IP65)
• All metal keytops
• 4,12 and 16 key formats
• 4 million actuation / key
• Permanent, high contrast, engraved key top legends
• Raised “Home PIP” on the “5” key
• Simple, “row and column” circuit matrix
• Can be fixed to a flat surface or under panel mounted for a flush, low profile installation
