Opto 22 IDC5B Module, DC Input, 50 mA, 4 to 16 VDC, 45 mA (Max.), 5 VDC, 0.05 ms, 0.1 ms

Opto 22 IDC5B Module, DC Input, 50 mA, 4 to 16 VDC, 45 mA (Max.), 5 VDC, 0.05 ms, 0.1 ms - gambar 1

Opto 22 IDC5B Module, DC Input, 50 mA, 4 to 16 VDC, 45 mA (Max.), 5 VDC, 0.05 ms, 0.1 ms - gambar 2

Opto 22 IDC5B Module, DC Input, 50 mA, 4 to 16 VDC, 45 mA (Max.), 5 VDC, 0.05 ms, 0.1 ms - gambar 3

Opto 22

Opto 22 IDC5B Module, DC Input, 50 mA, 4 to 16 VDC, 45 mA (Max.), 5 VDC, 0.05 ms, 0.1 ms

Name: Opto 22 IDC5B Module, DC Input, 50 mA, 4 to 16 VDC, 45 mA (Max.), 5 VDC, 0.05 ms, 0.1 ms
Brand: Opto 22
SKU: SKU005006
Price: 1270000 IDR
Availability: BackOrder

(27 ulasan) | SKU: SKU005006

Rp1.270.000

Lihat deskripsi & spesifikasi lengkap

100% Produk Original / OEM
Bergaransi resmi toko
Retur 7 hari untuk barang cacat / salah kirim
Pengemasan aman & rapi

Pre Order — barang akan disiapkan setelah pesanan dikonfirmasi

Deskripsi Produk

Manufacturer Part Number	IDC5B
Manufacturer	OPTO 22
Mounting Type	5 Pin I/O Mounting Board
Module Type	Input
Minimum Operating Temperature	-30 °C
Maximum Operating Temperature	70 °C
Number of Channels	1
Series	IDC Series
Input Current	45 mA A
Input Type	Digital
Isolation Voltage	4000 V
Special Features	Optical Isolation
Supply Voltage	5 VDC
Voltage Rating	4 to 16 V
Turn On Time	0.05 ms
Turn Off Time	0.1 ms
Temperature Operating Range	-30 to +70 C
Output Current	50 mA
Primary Type	Data Acquisition
Application	Limit Switches, Photoelectronic Switches, Proximity Switches, Push Button, Selector Switches
Type	Input
Input	4 to 16 VDC
Standards	CSA Certified, CE Marked, RoHs Compliant
Current Rating	50 mA
Connection to Host	Backplane

5 VDC Logical Voltage, 50 mA , DC Input Modules
• Low cost ?Input module for use in data acquisition applicationsThis module is a fast-switching input module for signals produced by photoelectric switches, encoders, DC proximity switches, or TTL devices.
