Opto 22 IDC24 Module, AC Input, 50 mA, 12 to 32 VDC, 25 mA (Max.), 5 VDC, 5 ms, 5 ms, 5 VDC

Opto 22 IDC24 Module, AC Input, 50 mA, 12 to 32 VDC, 25 mA (Max.), 5 VDC, 5 ms, 5 ms, 5 VDC - gambar 1

Opto 22 IDC24 Module, AC Input, 50 mA, 12 to 32 VDC, 25 mA (Max.), 5 VDC, 5 ms, 5 ms, 5 VDC - gambar 2

Opto 22 IDC24 Module, AC Input, 50 mA, 12 to 32 VDC, 25 mA (Max.), 5 VDC, 5 ms, 5 ms, 5 VDC - gambar 3

Opto 22

Opto 22 IDC24 Module, AC Input, 50 mA, 12 to 32 VDC, 25 mA (Max.), 5 VDC, 5 ms, 5 ms, 5 VDC

Name: Opto 22 IDC24 Module, AC Input, 50 mA, 12 to 32 VDC, 25 mA (Max.), 5 VDC, 5 ms, 5 ms, 5 VDC
Brand: Opto 22
SKU: SKU005177
Price: 1820000 IDR
Availability: BackOrder

(38 ulasan) | SKU: SKU005177

Rp1.820.000

Lihat deskripsi & spesifikasi lengkap

100% Produk Original / OEM
Bergaransi resmi toko
Retur 7 hari untuk barang cacat / salah kirim
Pengemasan aman & rapi

Pre Order — barang akan disiapkan setelah pesanan dikonfirmasi

Deskripsi Produk

Part Number Pabrikan	IDC24
Produsen	OPTO 22
Tipe Pemasangan	5 Pin I/O Mounting Board
Tipe Modul	Input
Suhu Operasi Minimum	-30 °C
Suhu Operasi Maksimum	70 °C
Satuan	EA
Jumlah Kanal	1
Seri	IDC Series
Arus Input	25 mA A
Tipe Input	Digital
Tegangan Isolasi	4000 V
Digunakan Dengan	Opto 22 Brains
Fitur Khusus	Optical Isolation
Tegangan Suplai	24 VDc
Rating Tegangan	12 to 32 V
Waktu Nyala	5 ms
Waktu Mati	5 ms
Rentang Suhu Operasi	-30 to +70 C
Arus Output	50 mA
Tipe Utama	Input
Aplikasi	Limit Switches, Photoelectronic Switches, Proximity Switches, Push Button, Selector Switches
Input	10 to 32 VDC
Standar	CSA Certified, CE Marked, RoHs Compliant
Rating Arus	50 mA
Koneksi ke Host	Backplane

5 VDC Logical Voltage, 50 mA , AC Input Modules
• Transient-free "clean" switchingAC input modules are used for sensing ON/OFF alternating current voltage levels.
