Opto 22 G4ODC24 Module, 5 to 60 VDC, 3 A @ 45 deg C (Ambient), DC, 1 mA (Max.), -30 to degC

Name: Opto 22 G4ODC24 Module, 5 to 60 VDC, 3 A @ 45 deg C (Ambient), DC, 1 mA (Max.), -30 to degC
Brand: Opto 22
SKU: SKU001521
Price: 1100000 IDR
Availability: BackOrder

(39 ulasan) | SKU: SKU001521

Rp1.100.000

Lihat deskripsi & spesifikasi lengkap

100% Produk Original / OEM
Bergaransi resmi toko
Retur 7 hari untuk barang cacat / salah kirim
Pengemasan aman & rapi

Pre Order — barang akan disiapkan setelah pesanan dikonfirmasi

Deskripsi Produk

Brand	OPTO 22
Connection to Host	Backplane
Contact Form	DC
Dimensions	1.92 in L X 0.16 in D
For Use With	SNAP PAC System
Input Current	18 mA A
Isolation Voltage	4000 V
Leakage Current	1 mA (Max.) uA
Manufacturer Part Number	G4ODC24
Maximum Operating Temperature	70 °C
Minimum Operating Temperature	-30 °C
Module Type	DC Output
Mounting Type	5 Pin I/O Mounting Board
Number of Channels	1
Number of IO Ports	1
Number of Outputs	1
Operating Temperature	-30 to 70 °F
Operating Voltage	5 to 60 V
Output	5 to 60 VDC
Output Type	Digital
Primary Type	Data Acquisition
Range Output	5 to 60 VDC
Series	G4 Series
Special Features	Optical Isolation
Standards	UL Recognized, CSA Certified, CE Approved
Supply Voltage	24 V
Temperature Operating Range	-30 to +70 C
Turn Off Time	50 μs
Turn On Time	100 μs
Type	Output

Opto 22 G4 I/O includes both digital and analog modules. Each G4 module offers compact single-channel packaging. Each digital module includes an LED status indicator and also is available with manual switching capability for field wiring and control logic testing. Digital modules support 5-, 15- or 24-volt logic. G4 digital output modules feature a top-mounted replaceable fuse. G4 analog modules are factory-calibrated, offer 12-bit resolution and require a single 24-volt power supply.
All current loop modules include an isolated loop power supply for added flexibility and reduced instrumentation costs. Input types include voltage, current, thermocouple, RTD, ICTD, frequency and velocity. Outputs include voltage, current and time-proportional output. Factory Mutual (FM) approved versions of many G4 I/O modules are available.
Contact Allied for details on specific models or visit Alliedelec.com for more information.
