Opto 22 G4IDC5MA Module, DC Input, 10 to 32 VDC, 25 mA (Max.), 5 ms, 5 ms, 5 VDC, 0 degC, 70 de
- 100% Produk Original / OEM
- Bergaransi resmi toko
- Retur 7 hari untuk barang cacat / salah kirim
- Pengemasan aman & rapi
Deskripsi Produk
| Manufacturer Part Number | G4IDC5MA |
|---|---|
| Manufacturer | OPTO 22 |
| Mounting Type | Opto 22 Analog Brick Mounted, Opto 22 Modular Controller Mounted |
| Module Type | DC Input |
| Minimum Operating Temperature | -30 °C |
| Maximum Operating Temperature | 70 °C |
| Number of IO Ports | 1 |
| Number of Channels | 1 |
| Series | G4 Series |
| Input Current | 12 mA A |
| Input Type | Digital |
| Isolation Voltage | 4000 V |
| Special Features | Optical Isolation |
| Supply Voltage | 5 VDC |
| Voltage Rating | 10 to 32 V |
| Turn On Time | 5 ms |
| Turn Off Time | 5 ms |
| Temperature Operating Range | -30 to +70 C |
| Output Type | Voltage |
| Output Current | 12 mA |
| Primary Type | Data Acquisition |
| Application | Data Acquisition, Energy Management, Industrial Automation, Monitoring |
| Type | Input |
| Input | 10 to 32 VDC |
| Standards | UL Recognized, CSA Certified, CE Approved |
| Connection to Host | Backplane |
Opto 22 G4 I/O includes both digital and analog modules. Each G4 module offers compact single-channel packaging. Each digital module includes an LED status indicator and also is available with manual switching capability for field wiring and control logic testing. Digital modules support 5-, 15- or 24-volt logic. G4 digital output modules feature a top-mounted replaceable fuse. G4 analog modules are factory-calibrated, offer 12-bit resolution and require a single 24-volt power supply.
All current loop modules include an isolated loop power supply for added flexibility and reduced instrumentation costs. Input types include voltage, current, thermocouple, RTD, ICTD, frequency and velocity. Outputs include voltage, current and time-proportional output. Factory Mutual (FM) approved versions of many G4 I/O modules are available.
Contact Allied for details on specific models or visit Alliedelec.com for more information.
