Opto 22 AD6 I/O Module, 5 VDC @ 170 mA, 0 to degC, UL, CSA, CE Certified

Opto 22 AD6 I/O Module, 5 VDC @ 170 mA, 0 to degC, UL, CSA, CE Certified - gambar 1

Opto 22 AD6 I/O Module, 5 VDC @ 170 mA, 0 to degC, UL, CSA, CE Certified - gambar 2

Opto 22 AD6 I/O Module, 5 VDC @ 170 mA, 0 to degC, UL, CSA, CE Certified - gambar 3

Opto 22

Opto 22 AD6 I/O Module, 5 VDC @ 170 mA, 0 to degC, UL, CSA, CE Certified

Name: Opto 22 AD6 I/O Module, 5 VDC @ 170 mA, 0 to degC, UL, CSA, CE Certified
Brand: Opto 22
SKU: SKU001977
Price: 5380000 IDR
Availability: BackOrder

(15 ulasan) | SKU: SKU001977

Rp5.380.000

Lihat deskripsi & spesifikasi lengkap

100% Produk Original / OEM
Bergaransi resmi toko
Retur 7 hari untuk barang cacat / salah kirim
Pengemasan aman & rapi

Pre Order — barang akan disiapkan setelah pesanan dikonfirmasi

Deskripsi Produk

Brand	OPTO 22
Connection to Host	Backplane
For Use With	SNAP PAC System
Input	0 to 5 VDC
Input Current	11 or 16 mA A
Input Type	Digital
Isolation Voltage	4000 VAC
Manufacturer Part Number	AD6
Maximum Operating Temperature	70 °C
Minimum Operating Temperature	0 °C
Module Type	Input
Mounting Type	5 Pin I/O Mounting Board
Number of Channels	1
Number of Inputs	1
Number of IO Ports	1
Operating Temperature	0 to 70 °C
Primary Type	Input
Response Time	8.5 ms (5% of Scale Change), 165 ms (63% of Scale Change) µs
Series	AD Series
Special Features	Optical Isolation
Standards	UL, CSA, CE Certified
Temperature Operating Range	0 to +70 C

Both analog and digital modules are available in Opto 22's G1 (or "Standard") packaging. G1 digital modules offer a wide range of voltage and speed combinations and are available for 5-, 15- or 24-volt logic. Analog modules offer 12-bit resolution. Analog input modules include voltage, current, thermocouple, RTD, ICTD and frequency. Both voltage and current analog outputs are available.G1 mounting racks include both digital and analog. G1 digital racks are available in 4-, 8-, 16- and 24-channel models and feature LED status indicators and plug-in replaceable fuses for each channel. G1 digital input and output modules can be combined on any G1 mounting rack. A G1 digital rack with screw terminals for both field and logic connections is available for custom application development targeted at isolating non-isolated devices such as PLCs. G1 digital racks are available for both direct connection and connection to Opto 22 Classic brain boards. G1 analog racks in 4-, 8- or 16-channel models accept Opto 22 G1 analog I/O modules. G1 analog racks are compatible with all Classic analog brain boards.
