Newhaven Display International NHD-10.1-1024600MB-LSXV-CTP TFT 10.1in, MVA Cap, 1024x600, LVDS Interface, 3.3-5V, TFT Displays Series

New Haven Display TFT Displays Series — Mountable TFT Modules:
The HDMI TFT Modules are our high-quality TFT displays paired with a custom designed PCB that supports HDMI interfacing for communication with the display. By utilizing the widely popular HDMI format, these modules do not need a separate controller board or multiple cable conversions to set up. Any controller with HDMI output can be directly connected to the HDMI TFT Modules via standard HDMI cable. After that, interfacing with the display and even a touch panel (connected via USB) can begin right away.
The HDMI interface has become the most popular video interface standard to date, and HDMI video sources are easier to come by now than ever before. Whether you need an HDMI TFT display for your Raspberry Pi/BeagleBone Black application, a Windows/Windows Embedded PC monitor, or a touch screen HMI for your Linux or other embedded system, the Newhaven Display HDMI TFT product line offers a solution. Available in 5.0”, 7.0”, and 10.1” size options, our HDMI TFT Modules unite our existing high-quality TFT display panels with a custom PCB engineered in the USA by Newhaven Display. Assembled to the display, our PCB provides the user an all-in-one, plug-and-play HDMI + USB Touch solution for virtually any application. - Our 10.1” models support 2-Channel Stereo Audio through HDMI.Features: HDMI TFT Module w/ USB-HID Capacitive Touch option On-board Analog Devices ADV7611 HDMI Receiver Plug-and-play USB-HID Touch, no external driver installation required 2-Channel Stereo Audio supported through HDMI; speaker terminal outputs HDMI (Type-A) Input Compatible with PC (Windows/Linux) Compatible with Linux based SBCs such as Raspberry Pi, BeagleBone, etc. 24-bit True Color, 1024x600 Resolution (WSVGA) High Brightness LED backlight with PWM 75deg Viewing Angles all sides 4 x Mounting Holes (#10-32), compatible with Rack Unit (RU) spacing Engineered in Elgin, IL (USA)
