Molex Woodhead/Brad 112038-0029 IO:PFB:IP67:60MM:8P:14DI/2DO:PNP; TCDPB-8C2P-B1U

Molex | BradControl HarshIO Series - PROFIBUS� Discrete I/O Modules for Harsh Environments:
The BradControl�� IP67 I/O modules provide a reliable solution for connecting industrial controllers to I/O devices in harsh environments. Contained in a 30mm wide housing rated for IP67 environments, BradControl I/O modules can be machine mounted and are able to withstand areas where liquids, dust or vibration may be present. This makes them ideally suited for many applications including material handling equipment and automated assembly machinery. To facilitate input and output device wiring, two versions of the BradControl Compact 30mm I/O modules for PROFIBUS are available; an 8 port format using M8 style connectors and a 4 port format using standard M12 threaded connectors or BradConnectivity���s new Ultra-Lock�� connection system, a "push-to-lock" method that provides a fast, simple and secure connection between the I/O module and I/O devices. With the Ultra-Lock connection system, performance and reliability are designed right into the connector! The unique radial seal design provides a reliable, operator independent seal each and every time. There�s no chance for under- or over-tightening. When you hear and feel the connector click, you know it�s locked in - there�s no guesswork. Other features include the support of both PNP and NPN inputs and current sourcing outputs. Built-in diagnostic tools include the highly visible LEDs which provide maintenance personnel with the ability to easily determine I/O, module and network status. PROFIBUS specific features include support of module and channel diagnostics through PROFIBUS and PROFIBUS Slave DP-V0 in accordance with EN 50170.
Features:-� Compact design allow s space savings for direct machine mount applications-� 4 port format uses standard M12 threaded connectors or Brad Connectivity Ultra-Lock connection system-� Standard hole pattern allow s for interchangeability with popular I/O modules-� Supports PNP and NPN inputs-� Choose from several I/O configurations-� Visible diagnostics through status LEDs-� Module and channel diagnostics supported through PROFIBUS-� Supports PROFIBUS Slave DP-V0 in accordance w ith EN 50170Applications:-� Machine tool industry-� Material handling systems-� Filling & packaging-� Steel industry
