Maple Systems HMC7-MIO-08 MODULE,HMC,4IN/2OUT,ANALOG

I/O Expansion Module | 4 Analog Inputs | 2 Analog OutputsThe HMC7-MIO-08 is one of several I/O expansion modules that attach to the back of Maple Systems Graphic HMCs. This module possesses 4 analog inputs and 2 analog outputs that support both voltage and current modes as well as RTD and Thermocouple modes. Easily tighten wiring to the terminals with a 3/32" flat blade screw driver.
Features:
Power: 3.9VDC from HMC7000 base, 24VDC 850mA maximum (user supplied)Isolation: I/O optically isolated from internal circuitAnalog Inputs: 4 (Voltage, Millivolts, Current, RTD (PT100( a1, a2), PT1000) and Thermocouple (TYPE J, K)Resolution: 16 bitCurrent Ranges: 0 to 20 mA, 4 to 20 mAVoltage Ranges: 0 to 10V, 0 to 5V, -10 to +10VMillivolt Ranges: 0-100mV, 0-50mVRTD Ranges: PT100 a1: -200 to 850 °CPT100 a2: -100 to 457 °CPT1000: -200 to 850 °CThermocouple Ranges: Type J: -210 to 1200 °C, Type K: -200 to 1373 °CInput Impedance: 1MΩ (V,mV, TC, RTD), 100O (mA)Maximum Input: ± 30VDC, 30mAAccuracy: 1% of full scaleAnalog Outputs: 2 (0 to 5V, 0 to 10V; 0 to 20mA, 4-20mA)Resolution: 16 bitAccuracy: 1% of full scaleLoad: 1 KΩ (Min) for V, 500Ω (Max) for mAConnection Method: Removable terminals (3.81mm pitch)
