Maple Systems HMC7-MIO-04 MODULE,HMC,8IN(4HS)/8OUT(NPN)

I/O Expansion Module | 8 Digital Inputs (4 High-Speed) | 8 Outputs (NPN)The HMC7-MIO-04 is one of several I/O expansion modules that attach to the back of Maple Systems Graphic HMCs. This module possesses 8 digital inputs (4 high-speed) and 8 outputs (NPN type). Easily tighten wiring to the terminals with a 3/32" flat blade screw driver.
Features:
Power: 3.9VDC from HMC7000 base, 24VDC 850mA maximum (user supplied)Isolation: I/O optically isolated from internal circuitDigital Inputs: 8 bidirectional inputs (4 high-speed – 25KHz)Rated Input Current: Up to 5mA (per contact)Input Impedance: 4.9KΩMinimum ON Voltage: 15VDCMaximum OFF Voltage: 5VDCTurn ON/OFF Time: 10msecSpecial Input Functions: High-Speed Channels: 4 inputs, X0, X2, X5 and X7Max. Input Frequency: 25KHzMax. Input Count: 4,294,967,295 (32-bit)Digital Outputs: 8 sinking outputs (NPN-type), 2 PWM outputs, Y2 and Y4Output Capacity: 500mA max per outputRated Load: 500mA @ 24VDC (300mA PWM)Total Output Capacity: 4A @ 24VDCConnection Method: Removable terminals (3.81mm pitch)
