Maple Systems HMC7-MIO-02 MODULE,HMC,8IN/8OUT,PNP

I/O Expansion Module | 8 Digital Bidirectional Inputs | 8 Digital Outputs (PNP)The HMC7-MIO-02 is one of several I/O expansion modules that attach to the back of Maple Systems Graphic HMCs. This module possesses 8 digital bidirectional inputs and 8 PNP-type digital outputs. Easily tighten wiring to the terminals with a 3/32" flat blade screw driver.
Features:
Power: 3.9VDC from HMC7000 base, 24VDC 850 mA maximum (user supplied)Isolation: I/O optically isolated from internal circuitDigital Inputs: 8 bidirectional inputsRated Input Voltage: 24VDCRated Input Current: Up to 5mAInput Impedance: 4.9KΩMin. ON voltage: 15VDCMax. OFF voltage: 5VDCTurn ON/OFF time: 10msecSpecial Input Functions: High-Speed Channels: 2 inputs, X0 and X5Max. Input Frequency: 25KHzMax. Input Count: 4,294,967,295 (32-bit)Digital Outputs: 8 sourcing outputs (PNP-type)Output Current: 0.5A maximum (per contact)Total Current: 4A maximumRated Load: 500mA@24VDCResistive: 48Ω / 12WInductive: 12VA (1.2H, 50Ω)Connection Method: Removable terminals (3.81 mm pitch)
