Maple Systems CMT3151 Smart HMI Display 15in Touchscreen 16.2M1024 x 76824VDC cMT3000 Series

Maple Systems cMT3000 Series — Smart cMT Family of IIoT Touchscreen HMIs, Servers and Communications Gateways:
This model comes with built-in EasyAccess 2.0 as well as OPC UA and MQTT servers, enabling users to remotely monitor and access HMIs in the plant via an Apple or Android tablet or smart phone.
The cMT3000 Series has all the features and capabilities available in our Advanced HMI line with the added benefit of builtin cMT Server functionality to communicate with up to 9 remote devices running the cMT Viewer application. All models are IIoT ready with support for MQTT, OPC UA, EasyAccess 2.0, and SQL database integration built-in, giving them the ability to act as an integral gateway between the plant floor and the outside world. Models come with either dual-Ethernet or Ethernet and Wi-Fi, ensuring network separation and increased security from unauthorized access. Two physical serial ports, a USB host port, and CAN Bus support are standard on these HMIs. They come with high performance Dual-Core Cortex-A9 1GHz CPUs, with 4GB Flash and 1GB RAM memory.
With display sizes ranging from 7 to 15 inches, cMT3000 HMIs offer the convenience of a local HMI display with the added benefit of built-in cMT Server functionality to communicate with remote devices running the cMT Viewer application. These all-in-one solutions also come with EasyAccess 2.0 and OPC UA pre-activated for truly secure remote access. Features:
• MQTT
• OPC UA Built-in
• SQL Database Integration
• EasyAccess 2.0 Pre-activated
• Modbus Gateway
• CAN Bus
• CUPS Ethernet Printer Driver
• Support
• PDF Reader
• CE, cULus, & RoHS Certified
• Barcode Scanner
• VNC
• USB and IP Camera Input
• Media PlayercMT3000 Models: cMT3072: 7” — resistive touchscreen display offers dual-Ethernet and a wide power input range allowing for installations into more diverse environments and control systems. IEC61131-3 programming via an additional CODESYS license. Combine your HMI and PLC logic into one unit.cMT3090: 9.7” — resistive touchscreen display offers dual-Ethernet, as well as a built-in mono speaker for playing sound effects and an SD card slot for expanded memory. IEC61131-3 programming via an additional CODESYS license. Combine your HMI and PLC logic into one unit.cMT3103: 10.1” — resistive touchscreen display offers a wide power input range and Wi-Fi connectivity, allowing for installations into more diverse environments and control systems where running network cabling is not possible.cMT3151: 15” — resistive touchscreen display offers dual-Ethernet, a micro USB client port, a built-in mono speaker as well as a 3.5mm audio out jack suitable for connecting external speakers for playing sound effects, and an SD card slot for expanded memory.
