IDEC Corporation FC5A-C16R2D PLC MICROSMART PENTRA 16I/O 12VDC
(33 ulasan)
| SKU: SKU038937
Rp10.100.000
Lihat deskripsi & spesifikasi lengkap
- 100% Produk Original / OEM
- Bergaransi resmi toko
- Retur 7 hari untuk barang cacat / salah kirim
- Pengemasan aman & rapi
Pre Order — barang akan disiapkan setelah pesanan dikonfirmasi
Deskripsi Produk
| Baud Rate | 57600 Bd |
|---|---|
| Brand | IDEC Corporation |
| Dimensions | 3.54 in L X 0.08 in D |
| Family Name | MicroSmart Pentra PLC Family |
| For Use With | MicroSmart Pentra |
| Input Current | 6 mA |
| IP Rating | IP22 |
| Manufacturer Part Number | FC5A-C16R2D |
| Maximum Operating Temperature | 55 °C |
| Memory | EEPROM, Card Slot |
| Minimum Operating Temperature | 0 °C |
| Mounting Type | DIN Rail/Panel Mount |
| Number of Inputs | 9 |
| Number of IO Ports | 13 |
| Number of Outputs | 4 |
| Output Current | 0.25 A |
| Output Type | Relay |
| Power Rating | 3.4 W |
| Primary Type | Controller |
| Scan Rate | 0.64 (End Processing), 1.16 (Basic Instruction) mS |
| Series | FC5A Series |
| Special Features | All-In-One CPU |
| Supply Current | 24 VDC @ 190 mA mA |
| Supply Voltage | 12 VDC |
| Temperature Operating Range | 0 to +55 C |
| Termination | screw |
| Type | PLC |
| Voltage Rating | 12 V |
Features:
• Program Capacity: 27 KB (16 points)
• Maximum I/O: 16
• Instruction Execution Time: - Basic Instruction LOD: 0.7 ?s - Advanced Instruction MOV: 33 ?s
• Enhanced Communication Functions: 10 I/O Type Available with Second Port
• High-Speed Counter Maximum Counting Frequency: - 50 kHz, Single/Two-Phase Selectable: 1 Point - 5 kHz, Single-Phase: 3 Points
• Floating Point Math Calculations
• Double-Word (32-Bit) Instruction Calculations
• User Communication Functions
