Eaton - Cutler Hammer XV-102-D8-57TVRC-10 HMI, 5.7in TFT Resistive Touch, Profibus-DP, CoDeSys Software, XV Series

Eaton XV Series — Touch Panel HMI/PLCs | XV and XP Series of Operator Interfaces:
The new XV and XP Series of operator interfaces represent the broadest set of solutions Eaton has introduced in more than 25 years of HMI innovation. This family of high performance platforms provide unmatched flexibility, with a slim OEM design and a variety of communication port options that include onboard Ethernet on all models. With screen sizes ranging from 3.5 to 15 inches, vast communications capabilities, and a single development software package, the XV and XP Series represent a complete solution to any HMI application.
Eaton’s XV Series of touch display PLCs offer high performance platforms that provide unmatched flexibility. Features slim OEM design and a variety of communication port options that include onboard Ethernet on all models. With screen sizes ranging from 3.5 to 15 inches, vast communications capabilities, and a single development software package, the XV and XP Series represent a complete solution to any HMI application.XV Series Operator Interface with Windows CE 5.0 Professional Operating System Features:
• 3.5-in to 10.4-in screen sizes in cost effective plastic or metal housing
• Ethernet and serial ports on all models
• Resistive touchscreen with flush bezel
• 64k color TFT display
• 40,000 hour LED backlight half-life with selectable dimming
• 24Vdc nominal rated power supply (-20%/+25%) with polarity protection
• 32 Bit RISC, 400 MHz Processor
• IP65, NEMA 4X (indoor)
• CE, UL/cUL, RoHS
• Ambient conditions are 0 to 50C, 10 to 95% relative humidity, non-condensing
• Pre-installed Visual Designer runtime and Web serving licenses for 1500 tags, three drivers and one Web session
• Field upgradeable to 4000 max tags, 3 drivers; 1, 2, 4, or 8XP Series Operator Interface with Windows Embedded Operating System Features:
• 8.4-in to 15.0-in screen and blind node
• Infrared touchscreen, non-reflective safety glass and metal housing for demanding environments
• Multiple Ethernet, serial, and USB ports on all models
• All solid-state media increases reliability
• Open architecture compatible with third party software and hardware
• Non-corruptible OS with Protect Mode increases security and minimizes emergency and preventative maintenance downtime
• Pre-installed Visual Designer runtime and Web serving licenses
• Ambient conditions are 0 to 50C, 10 to 95% relative humidity, non-condensing
• 24Vdc nominal rated power supply (–15%/+20%) with polarity protection
• 1 x PCI 32-bit slot for COMM modules
• CE, UL/cUL, RoHS
