Eaton - Cutler Hammer EU5C-SWD-PF1-1 Module, Powerfeed, 3A, 24VDC, for Use with SmartWire-DT Devices
(35 ulasan)
| SKU: SKU042217
Rp3.960.000
Lihat deskripsi & spesifikasi lengkap
- 100% Produk Original / OEM
- Bergaransi resmi toko
- Retur 7 hari untuk barang cacat / salah kirim
- Pengemasan aman & rapi
Pre Order — barang akan disiapkan setelah pesanan dikonfirmasi
Deskripsi Produk
| Brand | Eaton - Cutler Hammer |
|---|---|
| Family Name | Global Modular Family |
| For Use With | SmartWire DT PLC |
| Input Current | 3 A A |
| Manufacturer Part Number | EU5C-SWD-PF1-1 |
| Maximum Operating Temperature | 55 °C |
| Minimum Operating Temperature | -25 °C |
| Mounting Type | DIN Rail Mount |
| Primary Type | Power Supply Unit |
| Series | SmartWire-DT Series |
| Standards | CE Marked, UL Listed, cUL Listed, IP20 Rating |
| Supply Current | 3 A |
| Supply Voltage | 24 VDc |
| Temperature Operating Range | -25 to +55 C |
| UPC Code | 4015081160495 |
| Weight | 0.02 lb |
Powerfeed modules feed auxiliary 24 VDC power and/or 15 VDC network power into the SmartWire-DT flat cable. The auxiliary 24 VDC power is needed for the power supply of contactors and the 15 VDC network power is used for supplying power to additional SmartWire-DT nodes. Powerfeed modules are also used to create zone control or groups of devices controlled by a single Emergency Stop.
