Crouzet 88974153 Smart Relay, 26 I/O, 100-240 VAC, Expandable, Relay Output, Millenium 3
- 100% Produk Original / OEM
- Bergaransi resmi toko
- Retur 7 hari untuk barang cacat / salah kirim
- Pengemasan aman & rapi
Deskripsi Produk
| Brand | CROUZET |
|---|---|
| Communication Port Type | USB |
| Controller Type | XB26 |
| Dimensions | 4.24 in L X 0.16 in D |
| Family Name | Millenium 3 Smart Expandable Family |
| Input Type | Digital |
| Manufacturer Part Number | 88974153 |
| Maximum Operating Temperature | 70 °C |
| Minimum Operating Temperature | -20 °C |
| Mounting Type | DIN Rail/Panel Mount |
| Number of Inputs | 16 |
| Number of Outputs | 10 |
| Output Current | 8 A |
| Output Type | Relay |
| Primary Type | Controller |
| Scan Rate | 10 (Make) Off-Cycle Response, 255 (Functional Block) Response Time, 5 (Release) Off-Cycle Response, 50 (Ladder) Response Time |
| Series | XB10 / XB26 Series |
| Special Features | 70°C Operating Temperature, Expandable Version, Modbus Communication 2 x 8 Words with Read⁄Write Access, Network Creation Option Communication between 7 Millennium 3 Unit, Without Display |
| Standards | CE, CSA, GL, UL |
| Supply Current | 0 to 20 mA |
| Supply Voltage | 100-240 VAC |
| Temperature Operating Range | -20 to +70 C |
| Termination | screw |
| Type | PLC |
Crouzet Millenium 3 Smart Expandable Family | XB10 / XB26 Series — Without Display:
The Millenium 3 Smart logic controller is the easiest programmable module to use on the market. Easy to program thanks to M3 Soft, it enables the control and monitoring of machines and automation installations with up to 50 I/Os. Easy to program and to implement, it enables the control and monitoring of machines and automation installations with up to 50 I/O. It is positioned right at the heart of the Automation range. Millenium 3 offers both standard and customized product solutions for a range of applications, including automatic barriers, automatic doors, turnstiles, sectional doors and disabled access ramps.
The Millenium 3 logic controller and the em4 NanoPLC are the easiest to use programmable modules for various applications. With simple and intuitive software, controlling and monitoring of machines and automation installations is incredibly simple.
Smart Expandable Range Without Display Features: Efficient and economical version, without display or keys setting Allow the use of the entire library of specific functions blocs of the software workshop Extended temperature range (-30 °C ?+70 °C) Analogue inputs 0-10 VDC, Potentiometer, NTC, LDR (0-20 mA/Pt100 with converters) Open to XN network communication extensions, digital I/O, analogue, Pt100 extensions
