Crouzet 88974151 Controller, Expandable, Relay Out, XB26 Smart, 24VDC, Millenium 3

Crouzet 88974151 Controller, Expandable, Relay Out, XB26 Smart, 24VDC, Millenium 3

(23 ulasan) | SKU: SKU005122
Rp18.100.000
Lihat deskripsi & spesifikasi lengkap
Pre Order — barang akan disiapkan setelah pesanan dikonfirmasi

Deskripsi Produk

BrandCROUZET
Controller TypeXB26
Dimensions4.24 in L X 0.16 in D
Family NameMillenium 3 Smart Comapct Family
Manufacturer Part Number88974151
Maximum Operating Temperature70 °C
Minimum Operating Temperature-20 °C
Mounting TypeDIN Rail/Panel Mount
Number of Inputs16
Number of Outputs10
Output TypeRelay
Primary TypeController
Scan Rate10 (Make) Off-Cycle Response, 5 (Release) Off-Cycle Response mS
SeriesXB10 / XB26 Series
Special Features70degC Operating Temperature, Expandable Version, Modbus Communication 2 x 8 Words with Read/Write Access, Network Creation Option Communication between 7 Millennium 3 Unit, Without Display
Supply Current0 to 20 mA
Supply Voltage24 VDc
Temperature Operating Range-20 to +70 C
Terminationscrew
TypePLC

Crouzet Millenium 3 Smart Expandable Family | XB10 / XB26 Series — Without Display:
The Millenium 3 Smart logic controller is the easiest programmable module to use on the market. Easy to program thanks to M3 Soft, it enables the control and monitoring of machines and automation installations with up to 50 I/Os. Easy to program and to implement, it enables the control and monitoring of machines and automation installations with up to 50 I/O. It is positioned right at the heart of the Automation range. Millenium 3 offers both standard and customized product solutions for a range of applications, including automatic barriers, automatic doors, turnstiles, sectional doors and disabled access ramps.
The Millenium 3 logic controller and the em4 NanoPLC are the easiest to use programmable modules for various applications. With simple and intuitive software, controlling and monitoring of machines and automation installations is incredibly simple.
Smart Expandable Range Without Display Features: Efficient and economical version, without display or keys setting Allow the use of the entire library of specific functions blocs of the software workshop Extended temperature range (-30 °Cto+70 °C) Analogue inputs 0-10 VDC, Potentiometer, NTC, LDR (0-20 mA/Pt100 with converters) Open to XN network communication extensions, digital I/O, analogue, Pt100 extensions
